Delta DVP08SM11N – 8-Point Digital I/O Expansion Module

The DVP08SM11N is a slim digital I/O expansion module from the Delta PLC – DVP-S Series, designed to enhance your base PLC’s I/O capacity without compromising space. This module offers 8 digital I/O points in a compact DIN rail-mounted format and supports seamless integration with all right-side expandable Delta PLCs such as DVP-ES2, DVP-SS2, DVP-SX2, and DVP-SE.

🔍 Key Features – DVP08SM11N

• Model Type: Digital Mixed I/O Module

• Total I/O Points: 8 (4 DI + 4 DO)

• Input Type: 24 V DC (Sink/Source selectable)

• Output Type: Relay outputs

• Isolation: Optical isolation for digital inputs

• Mounting: DIN Rail

• Connection Method: Removable terminal block

• Status Indicators: LED indicators for each I/O point

• Compatible PLCs: DVP-ES2, DVP-SS2, DVP-SE, DVP-SX2 (right-side expansion)

📐 Technical Specifications

• Digital Inputs: 4 (24 V DC, sink/source)

• Digital Outputs: 4 Relay (250 V AC / 30 V DC, 2 A max)

• Response Time:

  • Input: <10 ms

  • Output (Relay): ~10 ms ON / ~5 ms OFF

• Isolation: Optical (inputs), Mechanical (relay outputs)

• Power Supply: 24 V DC (via main PLC)

• Operating Temperature: 0–55°C

• Mounting: DIN rail

• Protection Class: IP20

📐 Physical Dimensions

• Height: 90 mm

• Width: 25.2 mm

• Depth: 60 mm

• Weight: Approx. 110 g

🧰 Typical Applications

• Simple I/O expansion in space-constrained control panels

• Electrical panel relay logic extension

• General-purpose control for sensors, lamps, and solenoids

• Output expansion for pumps, motors, and actuators
