Delta DVP04PT-S – 4-Channel PT100 Temperature Sensor Input PLC Expansion Module

The DVP04PT-S is a 4-channel platinum temperature sensor (PT100) input PLC expansion module from the Delta DVP-S Series, designed to accurately measure temperature using PT100 sensors. Supporting 3-wire PT100 sensors compliant with DIN 43760 and JIS C1604-1989 standards, this module offers high-resolution temperature readings, making it ideal for precise thermal monitoring and control applications.

🔍 Key Features – DVP04PT-S

• Module Type: Temperature Measurement (PT100 Sensor Input)

• Analog Inputs: 4 channels

• Supported Sensor Type: PT100 (3-wire, 100Ω, 3850 PPM/°C)

• Measurement Range: -200°C to +600°C (-328°F to +1112°F)

• Resolution: 14-bit (0.1°C)

• Temperature Units: Selectable between Celsius (°C) and Fahrenheit (°F)

• Power Supply: 24 V DC (20.4 V DC to 28.8 V DC)

• Power Consumption: 2 W

• Mounting Type: DIN Rail

• Communication Interface: Built-in RS-485 (MODBUS ASCII/RTU)

• Termination Style: Pluggable Screw Terminal

• Operating Temperature: 0°C to 55°C

• Ingress Protection: IP20

• Certifications: CE, cULus

📐 Physical Dimensions

• Width: 96 mm

• Height: 90 mm

• Depth: 60 mm

• Weight: Approximately 190 g

🧰 Typical Applications

• Industrial temperature monitoring and control

• Process industries requiring precise thermal measurements

• Integration with SCADA systems for temperature data acquisition

• Applications involving furnaces, kilns, and thermal chambers
